Specificaties
| Algemene specificaties |
| Uitgangsspanning (± 5%) |
3 x 380 V - 50 Hz (± 0.05%) |
| Uitgangsfrequentie |
Pure sine wave |
| Nominale accuspanning |
24 V |
| P30 vermogen bij 40 °C, cos phi 1 |
10000 W |
| Continue vermogen bij 40 °C, cos phi 1 |
9000 W |
| Piek vermogen 20sec. |
30000 W |
| AC verbinding |
internal |
| Rendement |
92% |
| Display |
LED display |
| Minimale accubank (aanbevolen) |
> 600Ah |
| Afmetingen (h x b x d) |
700 x 316 x 575 |
| Gewicht |
60 kg |
| Keuringen/approvals |
CE, ABYC compliant |
| Technische specificaties |
| Technologie |
Toroidal transformer |
| Lage accuspanning, switch off |
19V ± 0.5V |
| Lage accuspanning, switch on |
22V ± 0.5V |
| Hoge accuspanning, switch off |
32V ± 0.5V |
| Hoge accuspanning, switch on |
30V ± 0.5V |
| Max. rimpel op DC (accu) |
5% RMS |
| Ingangsstroom (nominale belasting) |
800 A |
| Stand-by verbruik (AAN-modus) |
1.6 W standby |
| Kabeldiameter (min. aanbevolen) |
2x 7 mm² |
| Harmonische vervorming |
< 5% |
| Arbeidsfactor (cos phi) |
all power factors allowed |
| Omgevingstemperatuur |
-25°C to 80°C, derating > 40°Ca -13 to 176°F |
| IP-beschermingsgraad |
IP23 |
| Koeling |
natural/forced |
| Geluidsniveau |
48dBA at 1 mtr |
| Beveiligingen |
over heating, over load, short circuit, high battery, low battery |
| Accessoires |
| DC accukabels |
Pre-installed, max 2 metres |
| Afstandsbedieningspaneel |
Analogue on- off / DC-AC information |
| Afstandsbedieningspaneel |
Digital Power System Control Panel |
| WhisperSwitch |
Transfer switch Shore-Generator / Inverter |
|
